Mitsubishi D04FR Excavator Engine Turbocharged Intercooled 4.249L 4 Cylinder Engine
| Brand Name | Mitsubishi |
|---|---|
| Model Number | D04FR |
Product Details
| Engine Model | Mitsubishi D04FR (D04FR-KDP2TAAC, D04FR-74kW Variants) | Engine Type | Vertical, Inline 4-cylinder, 4-stroke, Water-cooled, Turbocharged With Intercooler Diesel Engine |
|---|---|---|---|
| Bore × Stroke | 102mm × 130mm (4.02in × 5.12in) | Displacement | 4.249L (4249cc/259.3 Cu·in) |
| Compression Ratio | 17.5:1 (standard Variant) | Rated Power | 74kW (99HP) @ 2000rpm (ISO 14396), 99HP (74kW) @ 2000rpm (gross Power) |
| Maximum Torque | 375Nm (276.6lb-ft) @ 1600rpm (depending On Variant) | Fuel System | Mechanical Direct Injection (DI) With High-pressure Fuel Pump |
| Firing Order | 1-3-4-2 | Cooling System | Forced Water Cooling With Thermostat + Aluminum Radiator + Oil Cooler |
| Lubrication System | Pressure Feed With Full-flow Filtration + Bypass Filtration | Oil Capacity | 12.5L (13.2qts) Including Oil Filter |
| Fuel Consumption | ≤220g/kW·h (at Rated Power, High Fuel Efficiency) | Starter Type | Electric Starter, 24V/5kW, With Glow Plug Cold Start System |
| Alternator | 24V/60A (80A Optional) | Dry Weight | Approx. 320-350kg (depending On Variant And Aftertreatment) |
| Dimensions (L×W×H) | 850mm × 630mm × 720mm (without Aftertreatment Unit) | Emission Standard | EU Stage IIIA, EPA Tier 3 (depending On Variant) |
| Key Features | Robust Construction, High Power Density (74kW/4.249L), Low Noise/vibration, Excellent Fuel Economy, Easy Maintenance, Cold Start At -20℃, 12000+ Hours Major Overhaul Period | Application | Kobelco SK130-8/SK140-8, SK135SR-2/SK140SR, New Holland E135B/E135BSRLC, 12-14 Ton Class Medium Excavators |
| Highlight | Mitsubishi Excavator Engine,Excavator Engine Turbocharged,D04FR 4 Cylinder Engine |
||
Product Description
Mitsubishi D04FR Engine Assembly
Complete 4-cylinder turbocharged intercooled engine assembly designed specifically for 13-ton excavators. This Mitsubishi D04FR engine delivers reliable power and performance for heavy-duty construction applications.
Key Features
- 4-cylinder diesel engine configuration
- Turbocharged and intercooled for optimal performance
- 4.249L displacement capacity
- Engineered specifically for 13-ton excavators
- Mitsubishi reliability and durability
- Complete assembly ready for installation
Technical Specifications
| Engine Model | Mitsubishi D04FR |
|---|---|
| Cylinder Configuration | 4-Cylinder |
| Displacement | 4.249L |
| Aspiration | Turbocharged with Intercooler |
| Application | 13-Ton Excavators |
This complete engine assembly ensures optimal performance and reliability for your heavy equipment needs, backed by Mitsubishi's engineering excellence.
