Yanmar 4TNV94L-BXPHZ Diesel Engine 3.053L 35.5kW 4 Cylinder For Excavators Forklifts
| Brand Name | Yanmar |
|---|---|
| Model Number | 4TNV94L-BXPHZ |
Product Details
| Engine Model | Yanmar 4TNV94L-BXPHZ (forklift & Excavator Dual-application Variant, TNV Series Premium Model) | Engine Type | Vertical, Inline 4-cylinder, 4-stroke, Water-cooled, Direct Injection (DI) Naturally Aspirated Diesel Engine With Electronic Control |
|---|---|---|---|
| Bore × Stroke | 94mm × 110mm (3.70in × 4.33in) | Displacement | 3.053L (3053cc/186.3 Cu·in) |
| Compression Ratio | 18.5:1 (standard Forklift & Excavator Variant) | Rated Power | 35.5kW (47.6HP) @ 2100rpm (net Power/ISO 9249/SAE J1349) |
| Maximum Torque | 210.6Nm (155.3lb-ft) @ 1260rpm (optimized For Forklift Load Handling & Excavator Digging Performance) | Fuel System | Electronic Direct Injection System (EDI) With High-pressure Mechanical Fuel Pump (MP Pump) |
| Firing Order | 1-3-4-2 | Cooling System | Mechanical Fan Drive, Forced Water Cooling With Aluminum Radiator + Closed Crankcase Ventilation (CCV) + Diesel Oxidation Catalyst (DOC) + Diesel Particulate Filter (DPF) For Tier 4 Final |
| Lubrication System | Gear Pump, Force-lubrication With Full-flow Filtration + Bypass Filtration | Oil Capacity | 7.0L (7.4qts) Including Oil Filter |
| Fuel Consumption | ≤215g/kW·h (at Rated Power, Excellent Fuel Efficiency For Dual Application) | Starter Type | Electric Starter, 24V/4.0kW × 1 (single Starter With Cold Start Aid System, -25°C Cold Start Capability) |
| Alternator | 24V/60A (70A Optional) | Dry Weight | Approx. 235-260kg (depending On Variant And Emissions Package) |
| Dimensions (L×W×H) | 761.4mm × 530.3mm × 800mm (engine Only) | Emission Standard | EPA Tier 4 Final (North America), EU Stage V (global Markets), With DOC+DPF+SCR For Tier 4 Final/Stage V Variants |
| Key Features | Robust Cast Iron Engine Block, Replaceable Wet Cylinder Liners, Forged Steel Crankshaft, Single Cylinder Head With 4 Valves Per Cylinder, Proven Reliability In Dual Application (forklift & Excavator), 8000+ Hours Major Overhaul Period, Specifically Designe | Application | 3-5 Ton Industrial Forklift, Doosan DX55, Hyundai R55-7, Liugong 906, Cat306, Sany SY60C 5-6 Ton Class Construction/landscaping/utilities Mini Excavators |
| Common Part Numbers | 129907-42000 (water Pump), 729962-51300/729963-51300 (fuel Injection Pump), 129935-51741 (fuel Injector), 129978-11700 (cylinder Head), 129907-13200 (exhaust Manifold) | ||
| Highlight | 3.053L Yanmar Engine,35.5kW Diesel Engine,EPA Tier 4 Final Engine |
||
Product Description
Yanmar 4TNV94L-BXPHZ Engine 3.053L 4-Cylinder
Product Overview
High-performance Yanmar 4TNV94L-BXPHZ diesel engine designed for industrial applications including forklifts and Doosan DX55 mini excavators. This reliable 4-cylinder power unit delivers exceptional durability and efficiency for demanding construction and material handling operations.
Technical Specifications
Engine Model:
4TNV94L-BXPHZ
Displacement:
3.053L
Cylinder Configuration:
4-Cylinder
Power Output:
35.5kW
Primary Applications:
Forklifts, Doosan DX55 Mini Excavator
Application Compatibility
This Yanmar engine is specifically engineered for compatibility with industrial forklifts and the Doosan DX55 mini excavator platform. Its compact design and robust construction make it ideal for space-constrained equipment requiring reliable power in challenging environments.
